| CPU | CPU | Intel® Raptor Lake-P Processor |
| CPU | TDP | 28W |
| Display | Graphic card | Intel® Iris® Xe Graphics |
| Display | Multi displays | 3 simultaneous 3 displays |
| Display | Interface | 2 x HDMI1.4, 1 x 80PIN（1 x HDMI2.0 4K60Hz) |
| Network | Lan IC | 1 x Realtek 8111H Co-Lay Intel Ethernet Connection I226LM |
| Network | Lan Interface | 10/100/1000Mbps |
| Network | Lan Connector | 1 x RJ45 Port |
| Network | Wireless Type | WIFI_BT module |
| Network | Wireless Interface | 1 x M.2 2230 slot for WIFI_BT module |
| Network | 4G/5G | Optional |
| I/O interface | Display | 2 x HDMI1.4 (4K@30Hz) Or One Can chose HDMI IN ; |
| I/O interface | USB | 2* x USB3.0,2* x USB3.1 ,1 x Type-c(USB3.2 date ) |
| I/O interface | Button | 1 x PowerButton, 1 x Clear CMOS Key |
| I/O interface | Slot | 1 x SIM Card Slot (Optional) |
| I/O interface | AUDIO | 1 x Line Out ; 1 x MIC-In |
| I/O interface | LAN | 1 x RJ45 |
| I/O interface | POWER | 1 x 2.5/5.5 DC-IN Connector |
| I/O interface | JAE | 1 x 80PIN JAE Support：1 x HDMI2.0 4K60Hz output,1 x DP1.4 5K60Hz output2 x USB2.0, 1 x USB3.0,1 x TTL |
| System | Memory | Dual channel SO-DIMM DDR5-4800MHz MAX 32G |
| System | Storage | 1 x KeyM M.2 2280 NVMe/SATA SSD 1 x KeyB M.2 2242 SATA SSD |
| System | OS | Windows11/Linux |
| System | WatchDog | Support |
| System | Auto Power On | Suppoer |
| System | RTC | Support |
| System | Power Input | 12~19V DC IN, 2.5/5.5 DC Jack & JAE 80p |
| System | Dimension | 119mm(L) x 180mm(W) x 30mm(H) |
| System | Operating Temp. | -5~45℃ |
| System | Operating Humidity | 10%~90% non-condensing |
| System | Storage Temp | -20~70℃ |
| System | Operating Humidity | 10%~90% non-condensing |
