| CPU | CPU | Intel® 10/11th Gen (Comet Lake/Rocket S ) Core™ Processors |
| CPU | TDP | Up to 65W |
| Display | Graphic card | Intel® UHD Graphics 630 for I3/I5/I7 CPU, Intel® UHD Graphics 610 for Pentium CPU |
| Display | Multi displays | Support 2 Displays |
| Display | Interface | 1 x HDMI-Out, 1 x VGA |
| Network | Lan IC | 1 x Realtek Lan IC |
| Network | Lan Interface | 1.0Gbps |
| Network | Lan Connector | 1 x RJ45 Ports |
| Network | Wireless Type | WIFI5 or WIFI6 |
| Network | Wireless Interface | M.2 2230 Key E With PCIe,USB2.0 and CNVi |
| Network | 4G/5G | N/A |
| I/O interface | Serial Port | N/A |
| I/O interface | USB | 4 x USB3.0，4 x USB2.0 |
| I/O interface | Button | 1 x PowerButton, 1 x Clear CMOS Key |
| I/O interface | SIM CARD | N/A |
| I/O interface | AUDIO | 1 x 3.5mm Line Out1 x 3.5mm Mic In |
| I/O interface | POWER | 1 x 2.5/5.5 DC-IN Connector |
| System | Memory | 2 x SODIMM DDR4 3200Mhz，Max 64GB |
| System | Storage | 1 x M.2 Key M 2280 for NVME/SATA SSD |
| System | OS | Windows 11/Linux |
| System | WatchDog | Support |
| System | Auto Power On | Support |
| System | RTC | Power on at specific time everyday |
| System | Power Input | 19v DC-In (2.5/5.5 DC Jack) |
| System | Dimension | 206mm(L) x 206mm(W) x 51mm(H) |
| System | Operating Temp. | 0~40℃ |
| System | Operating Humidity | 10%~90% non-condensing |
| System | Storage Temp | -20~70℃ |
| System | Operating Humidity | 5%~95% non-condensing |
