| CPU | CPU | Rk3566,Quad-core Cortex-A55 Up to 1.8Ghz |
| CPU | TDP | 6W |
| CPU | NPU | 1TOPS |
| Display | Graphics | ARM G52 2EE |
| Display | Multi displays | N/A |
| Display | Interface | 1 x HDMI-Out |
| Network | Lan IC | 1 x Realtek Lan IC |
| Network | Lan Interface | 10/100/1000Mbps |
| Network | Lan Connector | 1 x RJ45 Port |
| Network | Wireless Type | WIFI5 |
| Network | Wireless Interface | Onboard WIFI Module |
| Network | 4G/5G | N/A |
| I/O interface | Serial Port | N/A |
| I/O interface | USB | 1 x USB3.0，3 x USB2.0 |
| I/O interface | Button | 1 x PowerButton, 1 x Recover Key |
| I/O interface | IR | 1 x IR |
| I/O interface | AUDIO | 1 x 3.5mm Audio Jack (2 In 1) |
| I/O interface | POWER | 1 x 2.5/5.5 DC-IN Connector |
| System | Memory | Onboard DDR4 2GB (Support 1/4GB Option) |
| System | Storage | Onboard EMMC 8GB (Support 16/32/64GB Option) |
| System | OS | Android 11 |
| System | WatchDog | Support |
| System | Auto Power On | Support |
| System | RTC | Power on at specific time everyday |
| System | Power Input | 12v DC-In (2.5/5.5 DC Jack) |
| System | Dimension | 128mm(L) x 128mm(W) x 30mm(H) |
| System | Operating Temp. | 0~40℃ |
| System | Operating Humidity | 10%~90% non-condensing |
| System | Storage Temp | -20~70℃ |
| System | Operating Humidity | 5%~95% non-condensing |
