| CPU | CPU | RK3566，4 Core A55, 1.8GHz |
| CPU | TDP | 6 W |
| CPU | NPU | 1 TOPS |
| Display | Graphic card | ARM Mali-G52 |
| Display | Multi displays | Screen Mirroring |
| Display | Interface | 1 x HDMI-Out 4K @60Hz |
| Network | Lan IC | RTL8111H |
| Network | Lan Interface | 100/1000Mbps |
| Network | Lan Connector | 1 x RJ45 Ports |
| Network | Wireless Type | SDIO |
| Network | Wireless Interface | 1T1R, 2.4G/5G WiFi5 /BT4.2 |
| Network | 4G/5G | N/A |
| I/O interface | Serial Port | N/A |
| I/O interface | USB | 1 x USB3.0, 3 x USB2.0 |
| I/O interface | Button | 1 x Volume up, 1 x volume down, 1 x system settings, 1 x screen off, 1 x Power Button |
| I/O interface | SIM CARD | N/A |
| I/O interface | AUDIO | 1 x 3.5mm Audio Jack（Mic-In + Line Out） |
| I/O interface | POWER | 1 x 2.1/5.5 DC-IN Connector |
| System | Memory | 2GB LPDDR4/4X |
| System | Storage | 16GB EMMC |
| System | OS | Android 11 |
| System | LCD | 21.5 inch, 1920*1080 IPS, LVDS |
| System | MCU | Optional (Wake-on-LAN /Remote Shutdown /Watchdog /Auto Power On) |
| System | Camera | Optional Elevating Camera |
| System | Speaker | 2 x 8Ω / 3W |
| System | Power Input | 12v 2.1/5.5 DC-In |
| System | Dimension | 494mm(L) x 390mm(W) x 175mm(H) |
| System | Operating Temp. | 0~40℃ |
| System | Operating Humidity | 20%~80% non-condensing |
| System | Storage Temp | -20~65℃ |
| System | Operating Humidity | 20%~95% non-condensing |
