| CPU | CPU | Intel® Processor J6412 /N6415 |
| CPU | TDP | 6-15 W |
| Display | Graphics card | Intel® UHD Graphics |
| Display | Multi displays | Support Two displays |
| Display | Interface | 1 x HDMI-out 4K@60Hz , 1 x DP-out 4K @60Hz |
| Network | LAN IC | 1 x LAN IC 8111H |
| Network | LAN Interface | 10/100/1000Mbps |
| Network | LAN Connector | 1 x RJ45 Ports |
| Network | Wireless Type | M.2 Key E 2230 Module |
| Network | Wireless Interface | Mini PCIe WiFi/BT Module,Intel 3165/ Intel AX101 |
| Network | 4G/5G | Optional |
| I/O interface | Serial Port | 1 x RS232 COM Connector |
| I/O interface | USB | 3 x USB3.0, 5 x USB2.0 |
| I/O interface | Button | 1 x PowerButton, 1 x CMOS Button |
| I/O interface | SIM CARD | 1 x SIM Card slot |
| I/O interface | AUDIO | 1 x Line out , 1 x MIC-In |
| I/O interface | POWER | 1 x 2.5/5.5 DC-IN Connector |
| System | Memory | Dual LPDDR4 Max. 8 GB |
| System | Storage | 1* M.2 Key M 2280 Size For NVMe/SATA SSD |
| System | OS | Window11/Windows10/ Linux |
| System | Watchdog | Support |
| System | Auto Power On | Yes |
| System | RTC | Power On/Off at specific time, a week as a cycle |
| System | Power Input | 12v 2.5/5.5 DC-In |
| System | Dimension | 151mm(L) x 129mm(W) x 31mm(H) |
| System | Operating Temp. | -5~45℃ |
| System | Operating Humidity | 10%~90% non-condensing |
| System | Storage Temp | -20~70℃ |
| System | Operating Humidity | 5%~95% non-condensing |
